ELECTRICAL

CURRENT RATING:1.5AMPS

VOLTAGE RATING:125VAC

INSULATION RESISTANCE:500MEGOHMS MINI

WITHSTAND VOLTAGE:AC 1000V RMS 50Hz or60Hz 1MIN

CONTACT RESISTANCE:30MILLOHMS MINI

MECHANICAL

INSERTIONFORCE:2CONTACTS..350g 4CONTACTS..500g 6CONTACTS..750g

8CONTACTS..900g 10CONTACTS..1050g

RETENTION STRENGTH:7.7KgBETWEEN JACK AND PLUG

CRIMP TENSILE STRENGTH:2.27Kg

DURABILITY:750MATING CYCLES MINI

MATERIAL

HOUSING:1)PA66(UL94V-0) 2)GLASS FILLED PBT(UL94V-0) 3 ）PA9T （94V-0）

CONTACT WIRE:1)0.45mmDIA PHOSPHOR BRONZE GOLD PLATING OVER NICKEL

2)0.35mmTHICKNESS PHOSPHOR BRONZE ALLOY SELEOTIVE GOLD

PLATING OVER NICKEL

SHIELDING:0.25mmTHICKNESS COPPER ALLOY WITH TIN PLATED

GOLD PLATING：G/F u inch 3u inch 6u inch 15u inch 30u inch, 50u inch.

CONDITION:

USING CONDITION： -20 C~+55CRH 85% BELOW

STORING CONDITION:0C~32C,RH 65% BELOW
