Dual Port, 10/100 BASE-T Ethernet Transformer Modules, SMD，Rohs
Model： TGE-2407SR
Series： LAN Transformer Series
Download PDF
- Specification
- Drawing sheet
-
Dual Port, 10/100 BASE-T Ethernet Transformer Modules, SMD，Rohs HULYN Part Number T80E-2494SR Pulse Part Number HX1294NL Speed 10/100BASE-T Number of Ports DUAL Application - LAN ETHERNET (NON PoE) Package SMD Temperature - 40 TO + 85 AutomDX YES Comment SAME AS NL VERSION Configuration RX T,C,S Configuration TX T,C,S Construction OPEN FRAME Cores Per Port 12 Package Height (Inches) 0.225 Package Height (mm) 5.720 Package Length (Inches) 0.740 Package Length (mm) 18.80 Package Width (Inches) 0.537 Package Width (mm) 13.64 Turns Ratio RX 1CT:1CT Turns Ratio TX 1CT:1CT
