1000M Dual Ports Magnetic Module Transformer,96PIN

Model: TGE-9601DR
Series: LAN Transformer Series
Download PDF

Online Consultation

  • Specification
  • Drawing sheet
  • Designed for Ethernet 1000 BASE-T, full Quad port applications.
    Supports 16 pairs of category 5 UTP cable.
    Cable interface for isolation and low common mode Emissions.
    Compliant with IEEE 802.3ab standard for 1000 BASE-T.
    Comply with RoHS requirements-whole part No Cd,
    No Hg, No Cr6+, No PBB and PBDE and No Pb on external pins.
    Operating temperature range: 0℃ to +70℃.
    Storage temperature range: -25℃ to +105℃.
