產品型號: H181-32XXXX
產品系列: USB Type-C 连接器系列
PDF文檔下載

在線咨詢

  • 詳細介紹
  • 圖紙說明
  • SPECIFCATIONS:

    Contact current Rating:

       1.8 Amperes for pin1&pin4.

       0.25 Amperes other contacts

    Dielectric Withstanding Voltage:AC 100V(RMS)

    Insulation resistance:100Megohms Minimum.

    Contact Resistance:

       3OmΩ Max for pin1&pin4

       5OmΩMax for other contacts

    Mechanical Characteristics:

       Mating Force:3.5 Newtoms.Maximum

       Unmating Force:10 Newtoms.Mlnimum.

    Operating Temperature:-55 °C+85 °C
